Description
This Dakota Lithium 24-volt, 135 Ah lithium iron phosphate (LiFePO4) battery is built for trolling-motor runtime and combined starting and deep-cycle service. It is rated at 1000 cold cranking amps, so check your engine maker’s minimum cranking spec against that number. At roughly 54.4 lb, it takes meaningful weight out of the boat compared with a lead-acid battery of similar usable capacity. The case follows a BCI 24 footprint; confirm your tray size and terminal orientation before you buy. Internal heating protects the cells while charging in freezing weather. Pair it with a charger that offers a LiFePO4/lithium charge profile.
Highlights
- 24 V, 135 Ah LiFePO4
- 1000 CCA
- BCI 24 footprint
- 54.4 lb
- Internal heating for cold charging
- 11 year warranty
- Best for: Trolling Motor, Dual Purpose
Specifications
| Brand | Dakota Lithium |
|---|---|
| Model / SKU | PID12V135AHPLUSX2TMB |
| Nominal voltage | 24 V |
| Capacity | 135 Ah |
| Chemistry | Lithium iron phosphate (LiFePO4) |
| Cold cranking amps (CCA) | 1000 |
| BCI group size | 24 |
| Dimensions (L × W × H) | 9.5 × 6.9 × 8.22 in |
| Weight | 54.4 lb |
| Bluetooth monitoring | No |
| Internal heating (cold-weather charging) | Yes |
| Warranty | 11 year |
| Discharge | 135A max continuous discharge, 1000A max 2 second pulse, 900A max 5 sec pulse |
| Cycle life | Up to 80% capacity for 5,000 cycles in recommended conditions |
| Energy | 1620 Watt-hours (Wh) per battery |
| Terminals | F12 terminals (posts that screw in) with M8 size bolts |
| Reserve capacity | 340 minutes (RC25 @ 80°F) |
| Operating temperature | -4°F to 158°F (-20°C to 70°C) |
| Recommended charger | 24v 5A LiFePO4 charger is recommended |
Specs are from the manufacturer. Check your boat’s battery compartment, terminal layout and charging system before you order.
